Fiberglass Direct Roving 386H for Filament Winding
Fiberglass surface tissue S-FD30 for Wind Energy
Fiberglass surface tissue S-FD30 for Wind Energy
Fiberglass surface tissue S-FD30 for Wind Energy

Fiberglass Direct Roving 386H for Filament Winding

386H is a kind of blablabla fiberglass direct roving. Suitable for Filament winding

  • Description
  • Features
  • Material Properties
  • Application
  • Why Union
  • FAQ
  • Inquire Now

Description

Fiberglass surface tissue S-FD30 for Wind Energy


S-FD30 is a kind of epoxy compatible fiberglass surface tissue, suitable for RTM, vacuum infusion process for wind energy.


S-FD30 is ECR glass fiber tissue made by wet-laid process. It is produced by silane treated yarn which makes S-FD30 suitable for epoxy resin. Compared to other fiberglass tissue, it has higher temperature resistance, good for RTM, vacuum infusion process for wind energy. It is mainly used for wind turbine blades.

Features

Good surface effect

For RTM and vacuum infusion process, S-FD30 provides good surface effect, it is very good at covering the fiberglass texture for final products. In the manufacturing of wind turbine blades, S-FD30 is used to create a smooth, aerodynamic surface that enhances performance and durability.

Comparing to other materials, the cost of using fiberglass surface tissue is lower.

High temperature resistant glue

S-FD30 uses special glue. For RTM process, the resin curing time is short, the reaction exothermic peak 180℃ is reached quickly, so high temperature resistance can ensure that the good surface of the product without getting yellow.

Material Properties

Test Item

Unit

Standard

Area Weight

G/㎡

30±3

Water Content

%

≤0.5

Thickness

mm

≥0.3

Tensile Strength MD

N / 50 mm

40

Wetting Time

s

≤10

Application


Application Picture


Application Picture


Why Union

Union Composites


Union focuses on the manufacturing of composite materials and is the designated distributor of Jushi Group, which can provide customers with composite products of stable quality. Union is committed to meeting diverse customer needs and can customize products.



Contact UNION


  • icon01.png

    Suitable for Various Applications

    Open molding applications: Spray up and hand lay-up. Closed molding applications: Vacuum infusion processing, resin transfer molding, cold molding and compression molding.
  • icon02.png

    Price Advantage

    Advanced production technology brings lower costs, our selling prices are very competitive in the world.
  • icon03.png

    Fast Delivery

    Our production capacity is around 10tons every day. Usually lead time is around 1-2weeks for an order.


FAQ

  • Q: What product advantages do we have?A: Compared with our peers, we have lower prices. Regular specifications, such as 300G/450G are in good stock. COA and shipping pictures are available.

  • Q: What's your regular packing and Is it possible to pack in large rolls?A: If width is 1.04m, 2 vertical brackets are available.if width is more than 1.04m, the horizontal brackets are stacked on top of the vertical brackets.
    Pack in large rolls of course ok. 250m roll length, 550mm roll diameter, 1 bracket 4 rolls, no carton and with wooden frame.

  • Q: MOQ?A: We don't have min order quantity requirement, we can support our customers from small quantity.
    Free samples are available.

  • Q: How to ensure the stability of quality?A: Before producting, we will send samples to our customers and keep samples and labels.
    During producting, workers strictly control the quality to a large extent.
    After producting, COA is available which is consistent with the sample.

  • Q: Can the roll width be customized?A: Yes, we can customize the roll width for you.
    For CFM, the max width wecan produce is 1850MM.
    For CSM, the max width wecan produce is 3200MM.
